PingOne DaVinci

Launching a flow with a Ping SDK

Launch a prepared flow through an application built with one of the Ping SDKs.

The Ping SDKs provide powerful orchestration capabilities with PingOne DaVinci. They let you create flows to meet your use cases, while providing a native iOS, Android, or single-page app JavaScript experience.

This method is effective when you want complete control of your end user’s experience while using a flow behind the scenes.

Configuring the Flow

Prepare a flow to be launched with the Ping SDK for Android, iOS, or JavaScript.

About this task

This procedure only covers the steps and nodes required to prepare a flow for SDK invocation. It assumes that you’ve already created a flow for the purpose you have in mind. You can find more information about building flows in the Getting started with DaVinci and DaVinci Best Practices documentation.

Steps

  1. On the Flows tab, find the flow and click ... → Edit.

  2. Verify that your user interface nodes only use compatible connectors, capabilities, and fields.

    Compatible connectors and capabilities are:

    • The HTTP Connector and its Custom HTML Template capability

    Compatible fields within the Custom HTML Template capability are:

    • Text field: Lets the user enter text

    • Password field: Lets the user enter a password which cannot be read from the screen

    • Submit button: Lets the user submit field data and proceed

    • Flow button: Lets the user trigger a new process without submitting field data

  3. Verify that your flow does not depend on any unsupported elements:

    • SKPolling components: SKPolling components cannot be processed by the SDK and should not be included.

    • Variable field names: You cannot use variables or other values from a node’s input schema in the names of any field used by the SDK.

    • Images: Images included in the flow cannot be passed to the SDK.

    • Additional text: Titles or other text cannot be passed to the SDK.

  4. If you’re using HTTP Connector nodes, ensure that any buttons that submit page data use the following parameters:

    • type=submit

    • The data-skbuttonvalue must be Continue, Submit, Proceed, or Next.

      For example:

      <button data-id="button"
    type="submit"
    class="btn btn-primary mb-3"
    data-skcomponent="skbutton"
    data-skbuttontype="form-submit"
    data-skform="usernamePasswordForm"
    id="btnSignIn"
    data-skbuttonvalue="Submit">
Sign On
</button>

  5. If you’re using HTTP Connector nodes, ensure that any buttons that navigate to a different screen without submitting data use the following parameters:

    • The data-skbuttonvalue must not be Continue, Submit, Proceed, or Next.

      For example:

      <button data-id="button"
    class="btn btn-link"
    data-skcomponent="skbutton"
    data-skbuttontype="form-submit"
    data-skform="usernamePasswordForm"
    id="btnTrouble"
    data-skbuttonvalue="TROUBLE">
Having trouble signing on?
</button>

  6. If you’re using HTTP Connector nodes, add each text field, password field, and button to the node’s output fields.

    These outputs are all used by the SDK, regardless of any conditional logic used to control their display in the HTML.

    1. Click the node.

    2. On the General tab, find the Output Fields List section, and click Add.

    3. In the Property Name field, enter a name for the property to be passed to the SDK.

    4. In the Display Name field, enter a name for the property to be used in the user interface.

    5. In the Control Type list, select Text Field.

    6. In the Data Type list, select String.

    7. If the value is a password, select Secure.

    8. In the Value field, select the {} option and map the field’s value to the property.

    9. Repeat steps b-h for each additional output.

    10. Click Apply.

    11. Repeat these steps for each additional node with outputs.

  7. To use data about the invocation method or the invocation platform type in your flow, include the isSdk and platformType global parameters in your flow.

    Property Type Description

    isSdk

    Boolean

    Indicates whether the flow was launched using the SDK.

    platformType

    String

    Indicates what platform was used to launch the flow if it was launched using the SDK. Valid values are js, android, and ios.

    1. Open the node in which you want to include the invocation information.

    2. Click the Variables ( {} ) icon.

    3. Click Global > Current Request.

    4. Select the isSdk or platformType property.

      For example:

      A screen capture of the selection process described in steps a-d.

  8. Click More options ( ) > Flow Settings to show the flow settings.

  9. Select the PingOne Flow option.

  10. Click Save, then close the Flow Settings pane.

  11. End the flow with the following two PingOne Authentication nodes, one for success and one for failure.

    A screen capture of a flow ending with a success and failure path.
    Node Purpose

    Return a Success Response (Redirect Flows)

    This creates a PingOne session for the user and redirects the browser back to the source of the authentication request. This response provides the requested scopes as well as an access token or ID token.

    Return an Error Response (Redirect Flows)

    This redirects the browser back to the source of the authentication request. This response provides information about the error that occurred.

  12. Click Save, then click Deploy.

  13. If the main flow uses subflows, ensure that the subflows are not configured as PingOne flows.

    1. On the Flows tab, find the flow and click …​ > Edit.

    2. Click More options ( ) > Flow Settings to show the flow settings.

    3. Select the PingOne Flow option.

    4. Click Save, then close the Flow Settings pane.

    5. Repeat these steps for each additional subflow.

Creating a DaVinci application

Create an application in DaVinci to enable your flow.

Steps

  1. Sign on to DaVinci.

  2. On the Applications tab, click Add Application.

    Result:

    The Add Application modal opens.

  3. In the Name field, enter a name for the application.

  4. Click Create.

  5. Find the application and click Edit.

  6. On the OIDC tab, note the application parameters for the following:

    • Company ID

    • Client ID

    • Client Secret

    • Issuer

    • Token Endpoint

    • JWKS Endpoint

  7. Create a flow policy:

    1. On the Flow Policy tab, click Add Flow Policy..

    2. In the Name field, enter a name for the flow policy.

    3. Select PingOne Flow Policy.

    4. In the flow list, select your flow.

    5. In the version list, select Latest Version.

    6. Click Create Flow Policy.

      Result:

      The Edit Your Weight Distribution modal opens.

      This example only uses one flow, but if your flow policy included multiple flows or flow versions, you could use this modal to split traffic between them.

    7. Click Save Flow Policy.

    8. Note the Policy ID of your flow policy.

Configuring PingOne for flow invocation

Configure an application in PingOne to launch flows.

About this task

The PingOne application is used as part of the flow invocation process.

Steps

  1. Sign on to PingOne and go to Applications > Applications.

  2. Click the icon.

  3. In the Application Name field, enter a name for the application.

  4. In the Application Type section, select an application type corresponding to your platform:

    • If you’re using the Ping SDK for JavaScript, select OIDC Web App.

    • If you’re using the Ping SDK for iOS or Android, select OIDC Native App.

  5. Click Save.

  6. On the Policies tab, click Add Policies.

  7. On the DaVinci Policies tab, select one or more flow policies to add to the application.

    Only flow policies with the PingOne Policy option are displayed.

  8. Click Save.

  9. If you’re using the Ping SDK for JavaScript, configure CORS settings for your application.

    1. On the Configuration tab, click the Pencil icon.

    2. In the CORS Settings section, select Allow specific origins.

    3. In the Allowed Origins field, enter the domain from which you plan to launch the flow.

    4. Click Save.

  10. Create a revoke resource as described in the SDK documentation.

  11. Register OAuth 2.0 applications as described in the SDK documentation.

Invoking the flow

To launch the flow, construct a link with the PingOne details and add it to the resource that will launch the flow. You must download the Ping SDKs and create a user experience that launches the flow.

To create the link, you need the following values:

  • Client ID

  • Redirect URI

  • Scopes

  • OIDC Discovery Endpoint

Learn more about creating the link and launching the flow in the SDK documentation.
